19 PCS 40W Bee Eyes Head Light

Equipped with a magic light belt, make the effect more colorful, brighter lamp beads, beam dyeing effect is better. The lamp is equipped with 19*40W multi-color RGBW 4-in-1 LED, which produces vivid colors and excellent color mixing effect;
Also equipped with an electric zoom, the color of each led ring can be independently controlled to create an endless loop chase and graphic effects;
Contact Us
2
4
3
1

Details Introduction



The lamp is equipped with 19*40W multi-color RGBW 4-in-1 LED, which produces vivid colors and excellent color mixing effect;
540 degrees horizontal scan) (160 - bit precision electronic error correction/vertical scanning 220 degrees (160 - bit scan) precision electronic error correction, 24/26/38/81/95/100/102 ch international standard DMX512 channel, master-slave mode;
Electric zoom, the color of each led ring can be independently controlled, can create an endless ring chase and graphic effects;
With CTO, dyeing, light beam, effect mode (whirlpool, kaleidoscope), front mirror disk variable polar rotation, seamless splicing mirror disk, aspherical lens structure, lamp bead single point control lamp with effect stroboscopic, horse running effect, with built-in program.



Main features:

● Power supply :AC100V-240V50-60Hz Maximum power :1000W
● Light source :19 40W 4-in-1 OSRAM LED lamp beads

● Light belt :5050RGB74PCS0.12W magic side light belt

● Color temperature :2800K-8500K

● Lamp life: 50,000 hours
● Display: color screen

● Stroboscopic :1-25 times/second
● Spot Angle :0-60°
● Dimming :0-100% linear electronic dimming
● Control mode :DMX512, voice control, self-walking, master-slave

Low channel: 24/26/38/81/95/100/102 ch

● Functional effect: with CTO, dyeing, light beam, effect mode (vortex, kaleidoscope) front mirror disk variable direction endless rotation, seamless splicing mirror disk, aspherical lens structure, lamp bead single point control lamp with effect stroboscopic, horse running effect, with built-in program





Technical Specifications




Light Source

⊙ Light source: 19 40W 4-in-1 OSRAM LED lamp

⊙ Expected service life of lamp: 50000H



Optical system

⊙ Advanced optical system is used to ensure the clarity of the beam

⊙ Dimming: 0~100% linear dimming



Control and program

⊙ Control protocol: DMX512

⊙DMX control mode: 5 types

⊙ Control channel :24/26/38/81/95/100/102CH



X /Y axis

⊙X axis operating Angle: 540°

⊙ Y-axis operating Angle: 270°



Electrical and interface

⊙ Adaptive power supply

⊙ Input voltage range: AC220v,50Hz

⊙ Power socket: Power connector input/output (optional)



Luminaire specification

⊙ Lamp size: base length 28cm base width 27cm lamp body height 37cm

⊙ Net weight: 19kg



Working environment

⊙ Maximum ambient temperature: 40°C

⊙ Minimum operating temperature: 0°C

⊙ Maximum surface temperature: 65°C



Install

⊙ Can be mounted horizontally or vertically, not side hanging

Universal operating position



Factory configuration

⊙ Electronic Manual

⊙ Power Cable



Optional accessories

⊙ Rain cover

⊙ Light hook

⊙ Safety rope





Dimensional Drawing




Lllumination Diagram


Optional Accessories




Download
